Quartz by ACO Solid Linear Shower Drain Polished Chrome

Quartz by ACO Solid Linear Shower Drain - Polished Chrome

Solid - Clean and Sleek Architectural Design

Complete Set Channel Body, Solid Grate Cover, Lifting Key, Adjustable Feet, Hardware

Designed for wood joist shower installations with CPE waterproof membranes

Available Sizes

28 Inch (27.55" / 700mm), Intake 15.39 sq. in.
32 Inch (31.50" / 800mm), Intake 17.71 sq. in.
36 Inch (35.43" / 900mm), Intake 20.02 sq. in.
40 Inch (39.37" / 1000mm), Intake 22.35 sq. in.
48 Inch (47.25" / 1200mm), Intake 26.68 sq. in.
55 Inch (55.12" / 1400mm), Intake 31.01 sq. in.
60 Inch (59.05" / 1500mm), Intake 33.35 sq. in.

Linear Shower Channel Drains Provide Superior Performance and Contemporary Style

Features

• 2" diameter central vertical outlet
• Flow rate: 6.3 GPM (0.6 l/s) at the entrance and 9.5 GPM (0.6 l/s) against the wall
• 3.3" (84mm) wide channel
• Plastic support feet simplify installation and leveling
• Premium stainless steel construction
• Solid grate design for a clean, uninterrupted appearance
• Lifting key included for easy grate removal and maintenance

Polished Chrome Finish

The Quartz Solid linear shower drain features a clean, uninterrupted grate design that creates a bold architectural statement. Its minimalist appearance complements modern, transitional, and luxury bathroom designs while delivering outstanding drainage performance for residential and commercial showers.

ACO's Polished Chrome finish features a brilliant mirror-like surface that reflects surrounding finishes and adds a sophisticated contemporary touch. Although it is not chrome plated, the premium stainless steel finish is engineered for long-lasting durability and pairs beautifully with polished chrome, stainless steel, brushed nickel, and other cool-toned bathroom fixtures.

Manufactured from premium stainless steel, the Quartz Solid linear shower drain is engineered for years of dependable performance. The included lifting key allows easy grate removal for routine cleaning, while the adjustable support feet simplify installation and ensure precise leveling.

Unlike traditional center drains, the Quartz Solid linear shower drain provides greater installation flexibility by allowing placement against a wall, at the shower entrance, or in the center of the shower floor. The linear design creates a single-direction floor slope, minimizes complicated tile cuts, and makes it easier to achieve today's popular barrier-free walk-in shower designs.

Ideal for residential bathrooms, custom showers, hotels, spas, and commercial projects, the Quartz Solid collection combines European-inspired engineering with clean architectural styling to deliver dependable drainage, easy maintenance, and lasting beauty.

Helpful Resources

• Complete Guide to Design, Installation and Planning
• How to Install a Linear Shower Drain on a Joisted Wood Floor
• Quartz Linear Shower Drain Concrete Slab Installation Guide

Related Collections

• Quartz by ACO Shower Drains
• SereneDrains Shower Drains
• Shower Waterproofing Products

When installed correctly, the Quartz by ACO Solid Linear Shower Drain in Polished Chrome delivers dependable drainage, clean architectural styling, and long-lasting performance. Proper planning, waterproofing, and accurate installation help create a professional shower system that will perform reliably for years in both residential and commercial applications.
