SunTouch PM-DP Snow Sensor Control & Display Panel
Indoor Monitoring and Manual Control for Snow Melting Systems
The SunTouch PM-DP Snow Sensor Control and Display Panel provides convenient indoor monitoring and manual operation for ProMelt snow melting systems. Instead of guessing whether your snow melting system is operating, the PM-DP allows you to instantly verify system activity with easy-to-read LED indicators and simple push-button controls.
Compatible With:
SunTouch DS-2B, DS-224, DS-5, and DS-8 rain and snow sensor controllers.
Key Features:
- Convenient indoor monitoring of snow melt system operation
- Manual override for one complete delay-off cycle
- Self-powered design with no batteries or external AC power required
- Fits standard single gang electrical boxes
- Compatible with Decora and StyleLine cover plates
- User-selectable cover plate color and finish
- Supports optional home automation system connections
- Low power consumption at approximately 3.5 milliwatts
Simple Installation and Wiring
The PM-DP installs into standard single or multi-gang electrical boxes using the included mounting screws. The panel connects to the snow sensor through a CS-1 remote control and monitor cable using low-voltage 5-conductor wiring.
Recommended installation cable is 22 AWG shielded cable with a maximum installation distance of up to 800 feet from the connected snow sensor.
System Monitoring and Operation
The PM-DP provides three operating modes:
- Standby Mode
- Automatic Snow Detection Mode
- Manual ON Cycle
The Manual ON feature allows users to start one complete snow melting cycle without permanently overriding automatic operation. Once the drying cycle is complete, the system automatically returns to automatic snow detection mode.
Specifications:
- Dimensions: 4.1" x 1.8" x 0.9"
- Weight: 2.5 oz.
- Operating Temperature: -40°F to +185°F (-40°C to +85°C)
- Power Source: Supplied by connected snow sensor
- Maximum Cable Distance: 800 ft.
- Installation Location: Indoor or protected outdoor enclosure
Applications:
Ideal for residential and commercial snow melting systems where indoor monitoring, manual activation, and convenient system status visibility are desired.
Why Choose the SunTouch PM-DP?
- Instant confirmation of snow melt system operation
- Convenient indoor control access
- No additional power wiring required
- Clean professional appearance
- Reliable low-voltage operation
- Enhances overall ProMelt system usability
