Raimondi Gladiator Advance Bridge Wet Saw
Description
Description
Raimondi Gladiator Advance Bridge Wet Saw
Gladiator 85 (Pikus 85 ADV) Wet Saw 33-1/2" Rip Cut
Gladiator 105 (Pikus 105 ADV) Wet Saw 41-3/8" Rip Cut
Gladiator 130 (Pikus 130 ADV) Wet Saw 51-1/8" Rip Cut
For cutting granite, marble, porcelain, single and double fired, bricks, cement, etc.…
Includes for all models
- Raimondi Gladiator Tile Wet Saw Machine 110 V 60 Hz
- 10" Diamond Blade for Porcelain
- Easy transport. Telescopic legs can be retracted and two wheels can be used to move the machine around the job site.
- Key kit and Wrench
- Dressing Stone
- Easy-to-remove polypropylene tank for easy cleaning. Capacity 10 Gal
- Pump
- User and Maintenance Manual
| Specifications | WSGLA85 (Pikus 85 ADV) | WSGLA105 (Pikus 105 ADV) | WSGLA130 (Pikus 130 ADV) |
|---|---|---|---|
| Maximum Length of Cut | 33 1/2" | 41 3/8" | 51 1/8" |
| Maximum Thickness of Cut | 3 1/8" in single pass 6" in double pass | 3 1/8" in single pass 6" in double pass | 3 1/8" in single pass 6" in double pass |
| Maximum Blade Diameter | Ø 10", smallest blade diameter Ø 9" | Ø 10", smallest blade diameter Ø 9" | Ø 10", smallest blade diameter Ø 9" |
| Diagonal Cut | 23 5/8" x 23 5/8" | 29 1/2" x 29 1/2" | 35 3/8" x 35 3/8" |
| Overall Size | 50" x 27" x h 31" | 57" x 27" x h 31" | 68" x 27" x h 31" |
| Weight | 132 lb | 141 lb | 172 lb |
| Blade RPM | 2400 | 2400 | 2400 |
| Motor RPM | 3360 | 3360 | 3360 |
Feature for all Models;
- Adjustable cutting depth.
- Tilting motor assembly for bevel cuts from 0° to 45°.
- Belt driven system optimizes motor torque and cutting capacity. Gear ratio of motor to disc 1,4 ÷ 1. Drive belt type poly V.
- Cast and extruded aluminum framework.
- Easy-to-remove polypropylene tank for easy cleaning. Capacity (10 Gal).
- Heavy duty water pump and (2) jet nozzles (front or rear mounted) provide superior blade cooling.
- Sliding motor assembly with cast aluminum housing provided with 4 re-adjustable pulleys (double bearings). Extruded aluminum rail.
- Re-adjustable square for long lasting precision.
- Telescopic legs provided with double safety device to prevent collapsing.
- Floating blade guard remains in contact with tile to provide extra safety during operation.
- Pivoting blade guard remains parallel with tile to ensure maximum cutting depth.
EASY - Easy transport of all GLADIATOR machines. Telescopic legs can be retracted and two wheels can be used to move the machine around the job site.
CLEANING - Removal of work area tray for easy cleaning of the tray themselves and any large particles.
BASIN - Plastic basin on GLADIATOR machines can be removed from underneath without removing the aluminum trays. The basin slides out from the side for easy cleaning.
SQUARE - All GLADIATORS come with a square for 90° and 45° cuts.
SMOOTH PLUNGE - GLADIATORS perform smooth plunge cuts due to their four adjustable pulley system that run on extruded aluminum rail. Seen in the photo for a better, easier, and smoother pass. The image also shows on of our accessories, the tile holder!
PRECISION - Precise extension side square, seen here mounted onto the GLADIATOR 105, can be used on all GLADIATORS and ZIPPERS.
ROLLER BENCH - WSBROLL seen here being used with the GLADIATOR 105. This versatile side bench can be used with all Wet Saws or by itself.
EXTENSION - Extensions seen here mounted on each side of the GLADIATOR 105.
