Raimondi Diamond Satin Finish Wheel for Bulldog Machines - Step 4
Description
Description
Raimondi Diamond Satin Finish Wheel for Bulldog Machines - Step 4
The Raimondi Diamond Satin Finish Wheel is used in Step 4 of the Raimondi Bulldog bullnose profiling and finishing process. This red 800-grit wheel produces a satin finish after the honed finish stage and before the final gloss finishing step.
Choose the profile size that matches your application: 3/8" (10 mm) or 5/8" (15 mm). Both versions have a 5" (125 mm) diameter and a 25/32" (20 mm) arbor. Raimondi states that its wheels are tested and balanced to provide profiling results with compatible Bulldog machines.
Product Specifications
- Brand: Raimondi
- Application: Satin finishing for bullnose profiles
- Process stage: Step 4
- Wheel color: Red
- Finish: Satin
- Grit: 800 grit
- Available profile sizes: 3/8" (10 mm) and 5/8" (15 mm)
- Wheel diameter: 5" (125 mm)
- Arbor size: 25/32" (20 mm)
- Material: Hard-material resin
- Models: BDW38S4NT (3/8") and BDW58S4NT (5/8")
Choose Your Wheel Size
- 3/8" (10 mm): Model BDW38S4NT
- 5/8" (15 mm): Model BDW58S4NT
Five-Step Bullnose Profiling and Finishing Process
- Step 1 - Milling: The segmented milling wheel roughs out the profile shape.
- Step 2 - Rough Finish: The rough-finish wheel refines the initial profile.
- Step 3 - Honed Finish: The yellow wheel produces a honed finish.
- Step 4 - Satin Finish: This red 800-grit wheel produces the satin finish.
- Step 5 - Gloss Finish: The grey wheel completes the process with a glossy finish.
Compatible Machines
- Raimondi Bulldog BD1WD
- Raimondi Bulldog BD2WD
- Raimondi back-finisher BDSABF
- Raimondi back-finisher BDCBF
Additional Applications
Raimondi's milling and rough-finish wheels can also be used to create 45° bevels. Those wheels are available in 3/8" (10 mm) and 5/8" (15 mm) sizes. The satin finish wheel listed here is intended for the finishing stage, not the initial bevel shaping.
